5.16.10.2. Service Information Previous topic Parent topic Child topic Next topic

  • If an entry exists in the table for an FDS area, but no entry exists under the SDS area, all further digit strings are blocked (as of the SDS area).
  • Several LDSRT tables can also be assigned to one route.
  • A route in which the LDSRT test fails is not suitable to be inserted into a queue (Chapter  on page 433)
  • If a large number of entries are needed in the LDSRT table, it may be necessary to modify the value LCRDSR of the AM DIMSU, i.e. to further increase it.
  • This function can also be combined with other LCR features.

    Figure 32. Call Setup Procedure with Restriction Tables
